Custom Recipe Capability

MBD2 21.1.1

RecipeCapability<T> defines a kind of recipe content. It owns conversion, copying, editor controls, preview rendering, and recipe-viewer rendering. It does not store anything in a machine; a trait and handler provide that half.

This example adds integer “heat units” (HU). It reuses MBD2's SerializerInteger because the content is a scalar integer.

1. Implement and register the capability

java

public final class HeatUnitsCapability extends RecipeCapability<Integer> {
    @LDLRegister(name = "heat_units", registry = "mbd2:recipe_capability")
    public static final HeatUnitsCapability CAP = new HeatUnitsCapability();

    private HeatUnitsCapability() {
        super("heat_units", SerializerInteger.INSTANCE);
    }

    @Override
    public Integer createDefaultContent() {
        return 100;
    }

    @Override
    public UIElement createPreview(Supplier<Integer> content) {
        return new Label().bindDataSource(SupplierDataSource.of(() ->
            Component.literal(content.get() + " HU")));
    }

    @Override
    public UIElement createXEITemplate() {
        return new Label().setText("0 HU");
    }

    @Override
    public void bindXEIWidget(UIElement element, Content content, IO io) {
        if (element instanceof Label label) {
            String suffix = content.perTick ? " HU/t" : " HU";
            label.setText(Component.literal(of(content.content) + suffix));
        }
    }

    @Override
    public void createContentConfigurator(
            ConfiguratorGroup father,
            Supplier<Integer> supplier,
            Consumer<Integer> onUpdate) {
        // supplier::get, not supplier — NumberConfigurator takes Supplier<Number>,
        // and Supplier<Integer> is not one.
        father.addConfigurators(new NumberConfigurator(
            "recipe.capability.examplemod.heat_units",
            supplier::get,
            number -> onUpdate.accept(number.intValue()),
            100,
            true
        ).setRange(1, Integer.MAX_VALUE));
    }

    @Override
    public Component getLeftErrorInfo(List<Integer> left) {
        int missing = left.stream().mapToInt(Integer::intValue).sum();
        return Component.literal(missing + " HU");
    }
}

The annotation must be on a loaded public static field. MBD2 scans it, registers the value under heat_units, and then freezes MBDRegistries.RECIPE_CAPABILITIES.

Two optional overrides are worth knowing: xeiLayoutType() returns SLOT or BAR and decides where the recipe viewer places the widget, and calculateAmount(List<T>) supplies the number a progress display shows. ArsSourceRecipeCapability in MBD2's own source is the shortest complete scalar example.

2. Understand the serializer contract

For a custom T, implement IContentSerializer<T>:

Method	Responsibility
`of(Object)`	Convert Java/KubeJS/editor input into canonical `T`; reject or define fallback for unsupported types
`copyInner(T)`	Cheap copy used during recipe searches
`deepCopyInner(T)`	Independent copy for mutation; the default uses the codec
`copyWithModifier(T, ContentModifier)`	Apply parallel/chance/tier amount modifiers
`codec()`	Persistent recipe encoding
`streamCodec()`	Network encoding for registry-friendly buffers

Mutable content must never return itself from copyInner unless all search and handler code treats it as immutable. Scalar serializers may return the same boxed value.

3. Use it in Java and KubeJS

java

recipeType.recipeBuilder(id)
    .input(HeatUnitsCapability.CAP, 400)
    .output(HeatUnitsCapability.CAP, 50)
    .duration(100)
    .saveAsBuiltinRecipe();

ServerEvents.recipes(event => {
  const heat = MBDRegistries.RECIPE_CAPABILITIES.get('heat_units')
  if (heat === null) throw new Error('heat_units capability is not registered')

  event.recipes.example.heat_press()
    .id('example:anneal_plate')
    .inputs(heat, 400)
    .outputs(heat, 50)
})

MBDRegistries is a global KubeJS binding — no Java.loadClass needed.

The KubeJS call reaches RecipeCapability#of, which delegates to the serializer's of(Object). Make conversion errors explicit; silently returning zero creates recipes that appear valid but do nothing.

Recipe index keys

Newer than 21.1.2, a recipe type indexes its recipes by what their inputs need, so a search skips the recipes a machine plainly cannot run without simulating them. A capability takes part by overriding getLookupKeys(content): the keys an input content is filed under — holding any one of them may satisfy it, holding none never does. Items are filed under their Items, fluids under their Fluids. The default, null, means it cannot say exactly: such an input never rules a recipe out, which is always correct, only slower to search. Handlers report the other side through getAvailableLookupKeys(); see Recipe search and your extensions for the rules both sides follow.

4. Complete the engine

The capability is usable only after a runtime handler returns it from getRecipeCapability(). Continue with Custom traits to implement storage and simulate/commit handling.
