Java and Runtime API

The Java API loads the same authored FX used by the editor and owns a separate runtime instance for each playback.

Photon's public playback API is client-only. Load an immutable-ish FX definition, create or let an executor create an FXRuntime, and keep all world/render mutations on the client thread.

Add Photon to Your Mod

Photon, LDLib2 and KilaGraph are published to the FirstDark Maven. A mod that plays effects compiles against Photon and LDLib2. KilaGraph, the node graph library behind Photon's shader graphs, comes inside Photon's all jar, so you add it only when your own code uses KilaGraph classes.

Versions

Put the versions in gradle.properties:

minecraft_version=1.21.1
ldlib2_version=2.2.43
photon_version=2.2.9
# Only needed if you compile against KilaGraph (see below)
kilagraph_version=21.1.0.15

Requirement	Photon 2.2.9
Minecraft	1.21.1
NeoForge	21.1 (built against 21.1.217)
LDLib2	2.2.43 or later. Required; players install it next to Photon.
KilaGraph	21.1.0.15 or later. Required; nested inside Photon's all jar.
Mod ID	photon

A newer Photon release often needs a newer LDLib2. When you update Photon, check the LDLib2 version it requires.

Gradle

repositories {
    maven { url = "https://maven.firstdark.dev/snapshots" } // LDLib2, KilaGraph, Photon
}

dependencies {
    // LDLib2: the `all` jar carries LDLib2's own bundled libraries
    implementation "com.lowdragmc.ldlib2:ldlib2-neoforge-${minecraft_version}:${ldlib2_version}:all"
    // Photon: the `all` jar bundles KilaGraph
    implementation "com.lowdragmc.photon:photon-neoforge-${minecraft_version}:${photon_version}:all"
    // Only if your code uses KilaGraph classes directly (e.g. custom shader graph nodes):
    // compileOnly "com.lowdragmc.kilagraph:kilagraph-neoforge-${minecraft_version}:${kilagraph_version}"
}

repositories {
    maven("https://maven.firstdark.dev/snapshots") // LDLib2, KilaGraph, Photon
}

dependencies {
    val mc = property("minecraft_version")
    // LDLib2: the `all` jar carries LDLib2's own bundled libraries
    implementation("com.lowdragmc.ldlib2:ldlib2-neoforge-$mc:${property("ldlib2_version")}:all")
    // Photon: the `all` jar bundles KilaGraph
    implementation("com.lowdragmc.photon:photon-neoforge-$mc:${property("photon_version")}:all")
    // Only if your code uses KilaGraph classes directly (e.g. custom shader graph nodes):
    // compileOnly("com.lowdragmc.kilagraph:kilagraph-neoforge-$mc:${property("kilagraph_version")}")
}

Refresh the Gradle project. gradlew dependencies --configuration compileClasspath should then list one Photon and one LDLib2.

Why the all Jar

Photon publishes two jars for each version:

Jar	Contents
photon-neoforge-1.21.1-2.2.9.jar	Photon's classes only (the thin jar).
photon-neoforge-1.21.1-2.2.9-all.jar	The same classes plus KilaGraph 21.1.0.15, nested with NeoForge Jar-in-Jar.

The all jar is also the file on CurseForge and Modrinth, so players install only Photon and LDLib2. With the all classifier, your development run uses the same jar as players.

Photon's Maven metadata lists no compile dependencies. That is why the snippet declares LDLib2 itself: Photon's API uses LDLib2 types, and your code does not compile without them. In the development run, Gradle also adds KilaGraph as a runtime dependency of Photon. NeoForge then finds KilaGraph twice, at the top level and nested in Photon, and loads one copy, the highest version.

Older snippets

Earlier versions of this page used the thin coordinate with transitive = false. That still works, because the runtime jar is the all jar either way, but it is no longer needed. Leaving out the classifier also works: Gradle compiles against the thin jar and runs the all jar.

When You Also Need KilaGraph

Java cannot compile against classes inside a nested jar. Add KilaGraph as compileOnly when your code imports com.lowdragmc.kilagraph types, for example in custom shader graph nodes or in a subclass of a Photon class built on KilaGraph. Use the version that your Photon release bundles (21.1.0.15 for Photon 2.2.9). Players still get KilaGraph from Photon.

Declare the Dependency

Add Photon and LDLib2 to your neoforge.mods.toml:

[[dependencies.yourmodid]]
    modId = "photon"
    type = "required"
    versionRange = "[2.2.9,)"
    ordering = "AFTER"
    side = "BOTH"
[[dependencies.yourmodid]]
    modId = "ldlib2"
    type = "required"
    versionRange = "[2.2.43,)"
    ordering = "AFTER"
    side = "BOTH"

Do not declare KilaGraph; Photon declares and ships it. Set the lower bound of photon to the oldest version whose API you use. If your mod uses Photon only from client code and must also run on dedicated servers without Photon, use side = "CLIENT" for the photon entry.

For an optional integration, use type = "optional" and check ModList.get().isLoaded("photon") before you touch any class that imports Photon. Keep those imports in a separate class, so the JVM never loads it when Photon is missing:

public final class EffectsCompat {
    private static final boolean PHOTON = ModList.get().isLoaded("photon");

    public static void playHit(ClientLevel level, BlockPos pos) {
        if (PHOTON) {
            PhotonEffects.playHit(level, pos); // the only class that imports Photon
        }
    }
}

Test the guard with a run that does not have Photon on its runtime classpath. An unguarded reference fails with NoClassDefFoundError only when that code runs.

Bundle Photon inside your mod (Jar-in-Jar)

Bundle Photon only if installing your mod should also install Photon. If the player also installs Photon or LDLib2, or another mod bundles them, NeoForge loads the highest version.

dependencies {
    // `api` instead of `implementation` if your public types expose LDLib2, Photon or KilaGraph types
    jarJar(implementation(group: 'com.lowdragmc.ldlib2', name: "ldlib2-neoforge-${minecraft_version}", classifier: 'all')) {
        version { require "${ldlib2_version}" }
    }
    jarJar(implementation(group: 'com.lowdragmc.photon', name: "photon-neoforge-${minecraft_version}", classifier: 'all')) {
        version { require "${photon_version}" }
    }
    jarJar(implementation(group: 'com.lowdragmc.kilagraph', name: "kilagraph-neoforge-${minecraft_version}")) {
        version { require "${kilagraph_version}" }
    }
}

• Embed the all classifier for LDLib2 and Photon. The plain jars do not contain their nested libraries, so a build that compiles fine fails at runtime. KilaGraph has no all jar; its plain jar is the whole mod.
• Use require, not prefer. The three libraries depend on each other, so a prefer loses to their transitive constraints, and the compile and runtime classpaths can resolve different versions.
• Keep the [[dependencies]] entries in neoforge.mods.toml.

Troubleshooting

Symptom	Cause	Fix
NoClassDefFoundError or ClassNotFoundException for a com.lowdragmc.kilagraph class at runtime	The game runs or ships the thin Photon jar, which has no KilaGraph inside.	Depend on or bundle the all classifier.
package com.lowdragmc.lowdraglib2 does not exist, or "cannot access" an LDLib2 class, when compiling	LDLib2 is not on the compile classpath; Photon's metadata does not add it.	Add the LDLib2 implementation line.
"cannot access" a KilaGraph class when compiling	Your code uses KilaGraph types, which stay inside the nested jar.	Add KilaGraph as compileOnly.
The game stops while loading and reports a missing or too old ldlib2, kilagraph or photon	An installed version is below a declared range.	Update that mod, or check the ranges in your neoforge.mods.toml and gradle.properties.
Compiles, then fails at runtime on a missing class or method	The compile and runtime classpaths resolved different versions.	Run gradlew dependencies for both classpaths; use require when bundling.

How the API Fits Together

Minimal Playback

FX fx = FXHelper.getFX(ResourceLocation.parse("mymod:fire"));
if (fx != null) {
    new BlockEffectExecutor(fx, level, pos).start();
}

FX, FXRuntime, executors, particle objects, shader resources, and post processing are annotated or designed for client distribution. Do not reference them from code that a dedicated server must class-load; place integrations in client-only classes/events.

The first play of an effect reads its file, compiles its shaders and loads its textures. Preload the effects your mod plays often, so that work does not show as a hitch.

In This Section

• Loading, Listing, and Caching FX
• Preloading Effects
• Built-in Effect Executors
• FXRuntime Lifecycle
• Runtime Data Injection
• Runtime Objects and Transforms
• Live Meshes and UI Scenes
• Custom Executors, Timeline, and Signals
• Post Processing API
• Dynamic Lights API
• Extension, Serialization, and Debugging
