Post Processing Java API

Since 2.2.0

Java requests use the same Render Graph assets as Timeline clips and must be submitted for every frame in which the effect should remain active.

Submit an effect every render frame in which it should be visible.

IResourcePath effect = PhotonPostFX.parsePath("built-in:wiki_tint_effect");

PhotonPostFX.submit(effect, Map.of(
        "Tint", new Vector4f(1.0f, 0.35f, 0.2f, 1.0f),
        "Strength", 0.8f
), 0.65f);

parsePath accepts a full type(path) form or a built-in resource name. listEffectPaths() returns requestable Render Graph and bare Fullscreen Graph paths, matching /photonfx list.

Per-frame Request Model

submit(effect, params, weight) queues only the current frame. Weight is clamped to 0..1; null effect and non-positive weight are ignored. Stop submitting and the effect disappears next frame.

Submit from the client render-frame path appropriate to your ownership—not a server tick. If gameplay state is calculated on ticks, cache the state and submit its interpolated/render-safe value per frame.

Parameters

Parameter keys are exposed display names. Values may be Float, Vector2f, Vector3f, Vector4f, integer color, Boolean, and other types defined by the graph schema. Unknown/wrongly typed values fall back or fail resolution according to that parameter; consult the graph's Blackboard.

Multiple Requests

Requests for the same effect normally merge. Weight combines as 1 - Π(1 - wᵢ); lerpable parameters blend in ascending weight order, while non-lerpable values use the highest-weight request. Add reserved Independent=true only when each request must execute separately.

Mask-filtered requests can include the reserved mask filter parameter used by Timeline. Prefer Timeline UI or a shared integration helper instead of hard-coding internal reserved strings.

Isolated Stack

An executor can return a dedicated PostEffectStack from postEffectSink() for a separately rendered scene. Submit directly through stack.submit(...) in that context. PhotonPostFX.submit(...) always targets the global world stack.

Post effects also run when no Photon particle was drawn: the standalone pipeline consumes pending global requests over the main target. Iris/shader-pack execution moves to the compatible late render hook and obeys Photon client configuration.
