Hand-written Fullscreen Shaders

Since 2.2.0

A hand-written fullscreen shader is a Minecraft Core Shader dispatched by a Render Graph pass. Use one to port an existing post effect, write complex loops, or implement an algorithm not yet covered by Fullscreen Shader Graph. It shares the same fullscreen quad, HDR target pool, priorities, masks, and blending system as a graph pass.

Minimal Resource Layout

You normally do not need to write a vertex shader. Photon ships ldlib2:fast_blit through LDLib2; it receives fullscreen Position and outputs normalized texCoord.

assets/wiki/shaders/core/postfx/wave_tint.json
assets/wiki/shaders/core/postfx/wave_tint.fsh

The shader ID entered in Render Graph is wiki:postfx/wave_tint.

Complete Example

This pass reads the previous image from DiffuseSampler, applies a horizontal wave measured in pixels, and multiplies it by an adjustable tint.

{
  "vertex": "ldlib2:fast_blit",
  "fragment": "wiki:postfx/wave_tint",
  "samplers": [
    { "name": "DiffuseSampler" }
  ],
  "uniforms": [
    { "name": "DiffuseSampler_TexelSize", "type": "float", "count": 4,
      "values": [1, 1, 1, 1] },
    { "name": "ScreenSize", "type": "float", "count": 2,
      "values": [1, 1] },
    { "name": "GameTime", "type": "float", "count": 1,
      "values": [0] },
    { "name": "Strength", "type": "float", "count": 1,
      "values": [4] },
    { "name": "TintColor", "type": "float", "count": 4,
      "values": [1, 1, 1, 1] }
  ]
}

#version 150

uniform sampler2D DiffuseSampler;
uniform vec4 DiffuseSampler_TexelSize; // (width, height, 1/width, 1/height)
uniform vec2 ScreenSize;
uniform float GameTime;
uniform float Strength;
uniform vec4 TintColor;

in vec2 texCoord;
out vec4 fragColor;

void main() {
    float phase = texCoord.y * 40.0 + GameTime * 6.2831853;
    float offset = sin(phase) * Strength * DiffuseSampler_TexelSize.z;
    vec4 scene = texture(DiffuseSampler, texCoord + vec2(offset, 0.0));
    fragColor = scene * TintColor;
}

ScreenSize is not needed by this small algorithm; it is retained to demonstrate an engine-uniform declaration. A GLSL compiler may optimize away unused uniforms, and Photon safely skips a missing location.

Connect It to Render Graph

1. Create or open a Render Graph.
2. Add a Pass node.
3. Change Pass Source Type to Custom Shader.
4. Enter wiki:postfx/wave_tint as the shader.
5. The pass reflects DiffuseSampler, Strength, and TintColor ports from the JSON.
6. Connect Scene Color or an earlier pass output to DiffuseSampler.
7. Connect the pass output to Effect Output.

Strength and TintColor may be inline constants or Render Graph blackboard parameters overridden by Timeline or Java. To drive a uniform with request weight, connect Effect Weight to that value port. Hand-written shaders do not receive a mandatory built-in uniform named Weight.

After changing the JSON sampler/uniform interface, run Resource Reload and select the shader on the pass again so the node rebuilds its ports. The editor temporarily retains the last valid ports when the source breaks, but the Render Graph will not compile successfully.

Every Sampler Is a Texture Port

The JSON samplers array defines the pass texture inputs. Names have no fixed semantics:

"samplers": [
  { "name": "SceneColor" },
  { "name": "SceneDepth" },
  { "name": "NoiseTexture" }
]

This creates three required ports. They may connect to:

Render Graph source	Typical use
Scene Color	original HDR color or the output of lower-priority effects
Scene Depth	depth fade, DOF, and position reconstruction
Custom Mask	restrict an effect by mask group
Custom Depth	depth of marked Photon renderers
Earlier pass output	multi-pass blur, bloom, and compositing
Texture Input	LUT, noise, ramp, or a runtime texture parameter

Different from particle Custom Shader

Post FX does not use auto-bound names such as SamplerSceneColor or SamplerSceneDepth. A sampler's source is determined entirely by its Render Graph wire. Leaving any sampler unconnected fails graph compilation.

<Sampler>_TexelSize

For a sampler named DiffuseSampler, declare the matching suffix uniform:

uniform vec4 DiffuseSampler_TexelSize;

Photon writes (width, height, 1/width, 1/height). It does not become a value port and is intended for blur, outline, and other pixel offsets.

Scene, depth, mask, and pass outputs have known dimensions. When Texture Input comes from a fixed asset or runtime parameter, the executor may not know the source image dimensions, so the JSON default remains. Pass dimensions separately when such an algorithm requires them.

Exposed Custom Uniforms

CustomShaderPass turns only these JSON declarations into pass value ports:

JSON	Port type
"type": "float", "count": 1	float
"type": "float", "count": 2	vec2
"type": "float", "count": 3	vec3
"type": "float", "count": 4	vec4

Integers, matrices, and counts outside 1–4 are not exposed as parameter ports. JSON values are defaults. Every dispatch restores those defaults before applying pass constants, blackboard parameters, or Effect Weight, preventing values from a previous frame leaking into another execution.

There is no special color reflection rule. Represent a color as float/count 4 and pass it as a vec4 in Render Graph.

Engine Uniforms

The executor manages these names; they do not appear as pass ports.

Name	Type	Value
ScreenSize	vec2	current pass output target (width, height); a half-resolution pass receives half-resolution dimensions
GameTime	float	RenderSystem.getShaderGameTime(), normalized to 0..1 over one Minecraft day
ModelViewMat	mat4	camera view/model-view matrix captured for this image
ProjMat	mat4	projection matrix captured for this image
<Sampler>_TexelSize	vec4	(width, height, 1/width, 1/height) for a known input texture

Camera and Screen-space Uniforms

Since 2.2.3

Name	Type	Value
U_ViewPort	vec4	camera rectangle (x, y, width, height) in the pass target; the editor Scene may occupy only a sub-rectangle
kg_Time	float	seconds from the same clock as GameTime: GameTime × 1200
kg_ViewMat	mat4	captured view matrix
kg_IViewMat	mat4	inverse view matrix
kg_IModelViewMat	mat4	also inverse view on the current 1.21.1 camera path
kg_IProjMat	mat4	inverse projection matrix
kg_CameraBlockPos	vec3	integer block component of camera position
kg_CameraOffset	vec3	precision-split offset; absolute position is kg_CameraBlockPos - kg_CameraOffset

Normalize fragment coordinates through the viewport:

uniform vec4 U_ViewPort;

vec2 viewportUV = (gl_FragCoord.xy - U_ViewPort.xy) / U_ViewPort.zw;

This lets one shader work in the game fullscreen, the Photon editor sub-viewport, and downscaled passes. Use kg_IProjMat, kg_IViewMat, and the precision-split camera position when reconstructing positions from Scene Depth.

Writing a Vertex Shader

Prefer ldlib2:fast_blit. If a custom vertex shader is necessary, the pass uses DefaultVertexFormat.POSITION; its minimal interface is:

#version 150

in vec3 Position;
out vec2 texCoord;

void main() {
    gl_Position = vec4(Position.xy, 0.0, 1.0);
    texCoord = Position.xy * 0.5 + 0.5;
}

Vertex and fragment varying names/types must match. The quad already covers NDC -1..1; do not apply the model matrix of an ordinary world object.

Caching and Troubleshooting

• Shader JSON interfaces and compiled ShaderInstances are cached by shader ID.
• Resource Reload clears both caches; editing a file without reload does not reparse ports.
• Start with fragColor = texture(Input, texCoord) to verify wiring, then add depth, masks, and math.
• JSON must be valid: no comments or trailing commas.
• For a load failure, unreadable JSON, or missing sampler wire, inspect latest.log and the Render Graph compile error.

See Render Graph and Passes for pass/target wiring. Use Fullscreen Shader Graph when GLSL is unnecessary.
