Extension, Serialization, and Debugging

When an extension fails, verify registration and serialized type IDs first, then resource resolution, graph compilation, and the active render path.

Photon's authored model is registry-driven. Extensions are client registrations, not server gameplay registries.

Extension Points

Extension	Registry/type
FX Object	PhotonRegistries.FX_OBJECTS / static FXObjectType
Material	PhotonRegistries.MATERIALS / IMaterial supplier
Number Function	NUMBER_FUNCTIONS / NumberFunction supplier
Shape	SHAPES / IShape supplier
Model Source	MODEL_SOURCES / IModelSource supplier
Timeline Track	TIMELINE_TRACKS / static TrackType
Animated Property	ANIMATED_PROPERTIES / static AnimatedPropertyType

Built-ins use @LDLRegisterClient and static type singletons where required. A custom FX Object must provide its FXObjectType, codec/copy behavior, editor icon/configuration, runtime behavior, and serialization compatibility. A custom Timeline Track also needs a TrackEditor; registering only data does not create usable UI.

File Versions

Current .fxproj/.fx data uses FXProject.VERSION = 5. Versioned project data is migrated through PhotonFXProjectDataFixer; exported .fx loading wraps the root in project shape, applies fixes, then unwraps it. Unversioned historical .fx files use deserializers' legacy fallbacks because their true origin version is unknown.

Do not rewrite NBT fields by hand. Open and re-save old projects in the current editor, then re-export .fx/.fxpack. The short-lived format that embedded resources directly in .fx is unsupported; resources belong in an FX Pack.

Debug Checklist

1. FX missing: verify assets/<ns>/fx/<path>.fx, namespace case, pack mount, then inspect FXHelper warning.
2. Shader black/broken: inspect Core Shader/Graph compile log, reload resources, clear client FX cache.
3. Runtime stopped after world change: isValid() is expected to become false; create a new runtime for the new ClientLevel.
4. Graph data stays zero: enable GPU instancing and check the emitter/channel support matrix.
5. Iris differs: test with the supported Iris version and both no-pack/active-pack paths; check the Photon compatibility config.
6. HDR/Bloom differs: confirm material values exceed 1, HDR target is used, and post-effect priority is before/after Bloom as intended.

Performance

• Use GPU instancing for many equal tile/model/trail primitives; preserve common materials/layouts for batching.
• Parallel particle update helps computation-heavy collision-free emitters, but avoid unsafe external state in worker-updated modules.
• Keep RuntimeValue updates on the client thread and write only when ownership/value changes.
• Merge post-effect requests, downsample wide filters, and avoid Independent executions unless parameters truly must stay separate.
• Clear caches on resource lifecycle events, not every frame.
